General:

With tracking force, anti-skate and cartridge position preset at the factory, the McIntosh MT10 Precision Turntable delivers high performance LP playback with minimal set up. A custom tonearm features a rigid, dural-aluminum arm-tube gimbaled in two sapphire (horizontal) and two ceramic (vertical) bearings for the least possible friction. A .5mV moving coil cartridge is included, and features an ebony body with an elliptical stylus. Enjoy a new level of music with the MT10 turntable.

McIntosh Performance Features Include:
• Advanced Technology Turntable
The MT10 combines the latest technology in Phono Cartridges, Tone Arms, Mechanical Suspensions and Record Platter Rotation for superb performance and accurate operation.

• Moving Coil Cartridge
The McIntosh MCC10 Moving Coil Cartridge has a hand polished ebony wood-tone body and is slightly rounded, leading to a resonance free construction. High impedance, together with high output voltage, ensures noise free musical reproduction. The ruler-flat frequency response from 20Hz to 20kHz provides solid realistic bass, uncolored midrange and natural high frequencies.

• Tone Arm
The MT10 Tone Arm is made from Dural-Aluminum with special damping material. The Tone Arm is both light in weight and highly rigid. The noise free Vertical Bearings are made from two high precision ceramic surfaces with damping fluid. The Horizontal Bearing is a gimballed sapphire design.

• Turntable Platter
The over twelve pound, two and one-half inch thick platter is made from a special silicone acrylic material. This helps to resist external vibrations from reaching the record during playback and its large mass provides the perfect flywheel action for stable playback speed.

• Precision Motor and Drive Electronics
The Swiss made DC Brushless Motor is controlled by a highly refined servo control system. As the Turn- table Platter rotates, an optical sensor “reads” the 1595 micro stripes on a disk affixed to the bottom of the platter. This provides precise feedback information to the servo control system thus assuring very accurate speed rotation.

• Illuminated Speed Meter
The Illuminated Speed Meter on the MT10 indicates the true rotation speed of the turntable platter.

• Magnetic Air Dampened Bearing
The MT10 Turntable Platter rotates on a special bear- ing using magnetic suspension together with a cushion of air to provide vibration free rotation.

• Multi-Layered Dampened Chassis
The MT10 Turntable Chassis is composed from a Stainless Steel base plate, a thick Aluminum plate, an Acrylic plate and together with internal dampening material all help to assure the only sound heard is from the record groove itself.

• Power Control
The Power Control Input connection provides convenient Turn-On/Off of the MT10 Front Panel Illumination when connected to a McIntosh System with Power Control.

Brand Background:

Founded in 1949, McIntosh is known for offering distinguished home audio systems that deliver the ultimate experience in music and film. Offering products for two-channel stereo sound systems and multi-channel home theaters with surround sound, McIntosh continues to define the ultimate home audio entertainment experience for discriminating listeners around the world. Our iconic blue Watt output meter is globally recognized as a symbol of quality home audio. With a McIntosh home stereo system or home theater, listeners have the ability to create their own luxury audio experience Ð and truly live their music.

McIntosh products are designed and handcrafted at our Binghamton, NY factory by our dedicated employees who share a passion for music and the McIntosh heritage. Since our inception, McIntosh has been powering some of the most important moments in music history and pop culture. From President Lyndon JohnsonÕs inauguration speech to Woodstock to the famous Grateful Dead ÒWall of Sound,Ó McIntosh has not only witnessed history, we have shaped it.

Connections:

RCA outputs with Ground Wire, 12 Trigger in/out, power supply

Included:

MT10 Turntable, Owner's Manual, and the following accessories:

A. McIntosh MCC10 Moving Coil Cartridge.

B. AC / DC Adapter with plug adapters.

C. Tonearm Counter Weight.

D. Stylus Force Gauge.

E. Turntable Record Clamp.

F. Turntable Bubble Level.

G. Assembly/Adjustment Tools.

H. Cartridge Mounting Hardware.

I. Pair of cloth gloves.

J. Turntable Bearing Oil (full-synthetic).

K. Tone Arm Height Gauge (used for MCC10 Cartridge).

L. Protractor.

M. Cloth Dust Cover.

N. Turntable Platter Mat.

Note: The Turnable Platter Mat is located in an album cover and in the Turntable Platter/Accessory Carton.

Packing:

Factory Sealed McIntosh Carton

Overall Dimensions:

Width is 17-1/2 inches (44.45cm)
Height is 8-13/16 inches (22.38cm)
Depth is 21 inches (53.34cm)
Note: Tone Arm Height will vary depending on the type of Cartridge installed.

Weight:

42 pounds (19.0Kg) net

Reviews:

Click Here

Link to Manual:

Click Here

Link to Brochure:

Click Here

Recommended Cables:

Kimber Kable - Flagship Phono Interconnects - Best

McIntosh Power Control Cables

Specs:

CARTRIDGE SPECIFICATIONS

• Cartridge Type: Moving Coil, Low Output

• Output Level: 0.5 mV at 5 cm/s

• Load Impedance: 400 to 500 Ohms recommended

• Frequency Response: 20Hz to 50kHz

• Channel Separation: Greater than 30dB at 1Khz

• Compliance: 6 x 10^-6 cm/dyne

• Recommended Tracking Force: 2.4 g

• Channel Difference: Less than 0.3dB at 1kHz

• Total Mass: 11 g

• Stylus: Elliptical Diamond

• Cantilever Material: Aluminum

TONEARM SPECIFICATIONS

• Bearing: Sapphire and Ceramic

• Arm Tube: Dural-Aluminum

• Counterweight: Eccentric

• Adjustments: Vertical Tracking Angle, Antiskate, Azimuth

TURNTABLE SPECIFICATIONS

• Playback Speeds: 33-1/3, 45 and 78 rpm

• Motor Type: DC Brushless

• Speed Control: Electronic w/ braking feature

• Platter: Silicon Acrylic

• Platter Bearing: Magnetic Suspended Ceramic

• Signal To Noise Ratio: 41dB - 44dB

• Wow & Flutter: 0.10% - 0.15%
